PIN & BUSH GREASE
PRODUCT DESCRIPTION
Pin & Bush grease is a well-known, multi-purpose lithium grease. The grease allows the presence of very finegrade graphite which will fill surfaces and distribute the load evenly preventing further wear and tear. It is suitable for the lubrication of various industrial, agricultural, and earth-moving equipment applications.
APPLICATION
Pin & Bush grease is suitable for the lubrication of various industrial, agricultural, and earth-moving equipment applications.
PRODUCT ADVANTAGES
- The operating temperature range is -20°C to 130°C
- High level of lubricating solids that keeps working surfaces apart and substantially extends component life
- Being fully resistant to the wet environment extends the life of the lubricant and protects components from corrosion
- Adhesion improvers provide increased lasting protection
PACKAGING:
250gm, 500gm, 1kg, 3kg, 5kg, 10kg, 15kg, 180kg
TYPICAL PROPERTIES:
| PARAMETERS | TEST METHODS | TYPICAL VALUE | |
|---|---|---|---|
| NLGI Grade | – | 2 | 3 |
| Thickener type | – | Lithium Soap | Lithium Soap |
| Appearance | Visual | Smooth & Homogenous | Smooth & Homogenous |
| Color | Visual | Gray/ Black | Gray/ Black |
| Dry lubricant | – | Graphite | Graphite |
| Work Penetration @25°C | ASTM D217 | 265 – 295 | 220 – 250 |
| Copper Strip Corrosion 24hrs @100°C | ASTM D4048 | 1b | 1b |
| Dropping Point °C, Min | ASTM D2265 | 220 | 220 |
| Water Washout Resistance %Wt @79°C | ASTM D1264 | max 10 | max 10 |
| Four Ball Weld Load, Kgf, Min | ASTM D2596 | 250 | 250 |
| Operating Temperature Range °C | INTERNAL | -20 to 130 | |
| Base Oil Viscosity @40°C (Cst) | ASTM D445 | 180 | 180 |
HEALTH & SAFETY, ENVIRONMENT:
Prolonged and repeated contact with oil and grease may cause skin disorders. Avoid contact. Wash immediately with soap and water. For further information on Safety Guidelines please refer to MSDS available on our website www.rexol.uk
HEALTH & SAFETY:
This product is not likely to present any significant health or safety hazards when properly used in the recommended application and good standards of personal hygiene are maintained. Reference is made to the Safety Data Sheet (SDS) which is available on request via your local sales office or via the internet at www.rexol.uk
PROTECT THE ENVIRONMENT:
Take used oil and grease to an authorized collection point. Comply with local regulations. Do not discharge into drains, soil, or water.
STORAGE & HANDLING:
We recommend storing all packages under cover. Never leave grease containers improperly covered, uncovered, or open. Keep them tightly sealed between uses. If the containers are stored outside, a heavy canvas tarpaulin, plastic sheet, or lean-to can be used to keep off water or dirt. Ideally, grease should be stored in a cool, dry indoor area that does not exceed 86 degrees °F (30 degrees °C) and remains above 32 degrees °F (°C).
